MRC (SKF) 5310MFF

Specifications

• Bore Type
  Straight
• Bore Diameter
  50 mm
• Outside Diameter
  110 mm
• Overall Width
  1.7500 in
• Row Type Fill Slot
  Double-Row Filling Slot
• Closure Type
  Open
• Snap Ring Included
  Without Snap Ring
• Bearing Type
  Angular Contact Bearings
• Duplex Type
  Single
• Contact Angle
  30 °
• Bearing Material
  Chrome Steel
• Internal Clearance
  C3
• Radial Dynamic Load Capacity
  21400 lbf
• Seal Material
  Tinplate
• Radial Static Load Capacity
  21400 lbf
• Cage Material
  Steel
• Inner Ring Width
  44.4 mm
• Element Material
  Bearing steel
• Max Rpm
  5300 rpm
• Finish Coating
  Uncoated
• Precision Rating
  Not Rated
• Fillet Radius
  2 mm
• Series
  5300-M
• Weight
  4.20 lbs
• Manufacturer Catalog
  Click here
• Manufacturer Upc Number
  097741015042
