NTN 6009LLUC3

Specifications

• Bore Type
  Straight
• Bore Diameter
  45 mm
• Outside Diameter
  75 mm
• Overall Width
  16 mm
• Closure Type
  Double Sealed
• Row Type Fill Slot
  Single Row Non-Fill Slot
• Snap Ring Included
  Without Snap Ring
• Internal Clearance
  C3
• Operating Temperature Range
  -40 to 250 ºF
• Cage Type
  Pressed
• Precision Rating
  ISO Class 0
• Finish Coating
  Uncoated
• Bearing Material
  High Carbon Chrome Steel
• Cage Material
  Steel
• Inner Ring Width
  0.6299 in, 16.000 mm
• Fillet Radius
  0.0394 in, 1.000 mm
• Radial Dynamic Load Capacity
  5210 lbf
• Radial Static Load Capacity
  2590 lbf
• Manufacturer Catalog Number
  6009LLUC3/EM
• Manufacturer Upc Number
  4547359548204
• UPC_NO
  4547359548204
• Weight
  0.53 lbs
• Description
  6009LLUC3/EM BALL BRG
• Country of Origin
  JP
• Harmonization Code
  8482.10.5052
• Seal Material
  Nitrile Rubber
• Product Type
  Radial & Deep Groove Ball Bearings
• Long Description
  The 6009LLUC3/EM is a 45 mm bore radial/deep groove ball bearing with a 75 mm OD and 16 mm width, double sealed for long life.
