RHP 3202B N2ZR C3
RHP 3202B N2ZR C3
Low stock: 1 left
Regular price
$32.49 CAD
Regular price
Sale price
$32.49 CAD
Quantity
Couldn't load pickup availability
he 3202 NR is a double-row angular contact ball bearing equipped with an outer snap-ring groove and snap-ring (NR). It is a metric-series, open, non-filling slot bearing that accommodates heavy radial loads and axial loads in both directions
Dimensions
Inside Diameter (ID): 15 mm
Outside Diameter (OD): 35 mm
Width: 15.9 mm
Technical Specifications
Bearing Type: Double Row Angular Contact Ball Bearing
Contact Angle: Typically 25° to 30°
Dynamic Load Rating: ~ 11.2 kN to 12.4 kN
Static Load Rating: ~ 6.8 kN to 10.1 kN
Maximum Limiting Speed (Grease): ~ 12,000 to 13,000 RPM
Maximum Limiting Speed (Oil): ~ 16,000 to 18,000 RPM
